371 Non-Contact Digital Tachometer

Non Contact Digital Tachometer

371 non-contact tachometer measures rotating speed of shaft or disc with a point laser and reflective tape on the object being measured. These digital tachometers can measure output RPM or count readouts without interfering with the equipment being measured & without need of contact. Ideal for use for checking speed of revolution of motors , engines etc.

The measuring range of the RPM gauge is 0~99999 & RPM range is  10 RPM~99999RPM. The equipment has data hold & storage feature & output data can be transferred to PC through USB cable.

371 Tachometer is used for monitoring of motor's speed, counting, process control, and ratio/draw application of equipment like conveyors, windmill, rotary feeders, grinders etc.

Specifications
Product Specification

Measurements

Range

371

Display Count

100000


RPM Range

10RPM~99RPM

± (0.03%)

100RPM~999RPM

± (0.04%+2)

1000RPM~9999RPM

± (0.04%+2)

10000RPM~99999RPM

± (0.04%+2)

Counts

Range: 0~99999




Max. Input Frequency: 10kHz; Bandwidth: 5%

Target Distance

50mm~200mm

Other Features

Data Hold

Auto Power Off

Low Battery Indication ≤4.8V

MAX/MIN/AVG Mode

General Characteristics

Power

1.5V Battery (LR6) X 4

Display

53mm x 41mm

Product Net Weight

100g

Product Size

184mm x 56mm x 34mm

Standard Accessories

Reflective Tape

Features
Features
  • Data hold
  • Backlight
  • Auto power off
  • Auto range
  • Overload indication
  • Low battery indication
  • 1m drop proof


FAQ
FAQ
Frequently Asked Questions (4 answered questions)
10 RPM to 99999 RPM

Person name: Asian

Yes

Person name: Asian

yes

Person name: Asian
