Optical Power Meter is used to measure the power of an optical signal in an optical fiber. Fiber optic power meter performs received optical power measurements on fiber optic cabling networks sets.
Fiber Optic Power Meters are available in two model variants with Range T: +8~-70dBm for Telecom; Range C: +26~-50dBm for cable tv users.
Optical power meters are offered in various model & configuration with feature options such as multi wavelength display in Auto test mode (Auto wave ID mode, when used with corresponding Optical Laser Source) ensures fast multi wavelength optical testing by a single person, on one screen, for real time measurement of optical transmission power of multiple wavelengths received, displayed on a bright colour LCD display.
Options include threshold setting feature and data storage up to 1000 traces, we provide the most dependable and highly stabilised Optical power meters.
Stanlay offers a wide range of Optical power meters for testing single- mode and multimode fiber networks at different wavelengths 850/ 1300/ 1310/ 1490/ 1550/ 1625nm.
Optical Power Meter Selection Guide
|
Category |
Advanced |
Advanced |
Economy |
Economy Range |
||||
|
Model |
AOP100 |
|||||||
|
Module Selection |
T |
C |
T |
C |
T |
C |
T |
C |
|
Display Range |
1310/1490/ 1550/1625: +10~-70dBm 850/1300: +10~-60dBm |
1310/1490/ 1550/1625: +26~-50dBm 850/1300: +26~-40dBm |
1310/1490/ 1550/1625: +10~-70dBm 850/1300: +10~-60dBm |
1310/1490/ 1550/1625: +26~-50dBm 850/1300: +26~-40dBm |
1310/1490/ 1550/1625: +10~-70dBm 850/1300: +10~-60dBm |
1310/1490/ 1550/1625: +26~-50dBm 850/1300: +26~-40dBm |
1310/1490/ 1550/1625: +6~-70dBm 850/1300: +6~-60dBm |
1310/1490/ 1550/1625: +26~-50dBm 850/1300: +26~-40dBm |
|
Multi-Wavelengths Display in AUTO WAVE ID Mode |
Yes |
No |
No |
No |
||||
|
Data Storage |
1000 traces |
40 traces |
No |
No |
||||
|
Threshold Setting |
10 sets |
No |
No |
No |
||||
|
Auto Wave ID detect |
Yes |
Optional |
Optional |
No |
||||
|
Accuracy |
± 0.2 dB |
± 0.2 dB |
± 0.2 dB |
± 0.2 dB |
||||
|
Linearity |
± 2 % (0.087dB) |
± 2 % (0.087dB) |
± 2 % (0.087dB) |
± 2 % (0.087dB) |
||||
|
Sensor Type |
InGaAs |
InGaAs |
InGaAs |
InGaAs |
||||
|
Wavelength (nm) |
850/ 1300/ 1310/ 1490/ 1550/ 1625 |
850/ 1300/ 1310/ 1490/ 1550/ 1625 |
850/ 1300/ 1310/ 1490/ 1550/ 1625 |
850/ 1300/ 1310/ 1490/ 1550/ 1625 |
||||
|
Resolution |
0.01dB/0.001µW (1nW) |
0.01dB/0.001µW (1nW) |
0.01dB/0.001µW (1nW) |
0.01dB/0.001µW (1nW) |
||||
|
Connector Adaptor* |
FC (or SC) & 2.5mm UPP * |
FC (or SC) & 2.5mm UPP * |
FC (or SC) & 2.5mm UPP * |
2.5mm universal |
||||
|
User Defined Wavelengths |
10 |
No |
No |
No |
||||
|
REF |
Yes |
Yes |
Yes |
Yes |
||||
|
Back Light |
Yes |
Yes |
Yes |
No |
||||
|
LED Light |
No |
No |
No |
. | ||||
