High Sensitivity Leakage Current Clamp Meter 251A/C

251 series high-accuracy high sensitivity leakage current clamp meters are designed for testing AC leakage current. These high-resolution meters are great for applications such as checking leakage current for motor, home appliances and other electrical equipment up to 600A

Request Quote
High Sensitivity Leakage Current Clamp Meter 251A/C
Features Specifications FAQ Downloads



Features
  • 4-digit LCD digital display, 10000 display count
  • Auto range, 2/s sampling rate
  • Peak hold
  • Stores 99 sets of data
  • RS-232 interface
  • Data hold, Auto power off
  • Overload indication, low battery indication



Specifications

Model Selection

Range

251A

251C

Auto Range

           √

Display

-

4 Digit LCD Display

4 Digit LCD Display







Leakage Current (A)

0.001mA～60A

± (1.5%+5)

± (1.5%+5)

60A～199.9A

-

± (2%+5)

200A～300A

-

± (3%+5)

300A～600A

-

± (4%+5)

Voltage (Freq.) 0V~600V (50Hz/60Hz)

√

√

Resolution

1uA

1mA

Other Features







Display Mode

4 Digits LCD

√

√

Clamp Size

-

25mm x 30mm

35mm x 40mm

RS-232

√

Data Storage

99 Data Sets

Peak/Data Hold

√

Overload Protection

√

Auto Power Off (5 Minutes)

√

Low Battery Indication ≤7.2V

√

Over-Range Display

√

Test Mode

(Clamp Ct, Integral Mode)

√

Category Safety Ratings

CAT III 600V

General Characteristics

Power

9V Battery (6F22)

Display

32mm x 15mm

Product Net Weight

120g

Product Size

175mm x 70mm x 38mm

Standard Accessories

Battery, RS-232 Interface Cable, PC Software CD, Toolbox
