Fiber Cleaver CLV-N2
CLV-N2
Fiber Cleaver CLV-N2
Fiber Cleaver CLV-N2
Fiber Cleaver CLV-N2 CLV-N2 Fiber Cleaver CLV-N2 Fiber Cleaver CLV-N2

Fiber Cleaver CLV-N2

Stanlay CLV-N2 is a high-efficiency auto-return fiber cleaver designed for fast and repetitive fiber cleaving during fiber optic and FTTH installation and maintenance. Equipped with an auto-return mechanism, integrated fiber dustbin, and FTTH fiber holder, the CLV-N2 enables technicians to perform continuous cleaving efficiently while keeping fiber scraps safely collected.

The cleaver features a 24-position blade with a blade life of up to 48,000 cleaves, providing long-term operation while maintaining consistent cleaving performance. It supports 125 μm bare fiber and 250 μm / 900 μm coated fiber, with an adjustable cutting length of 5–20 mm, making it suitable for bare fiber and indoor cable applications.

Request Quote
Fiber Cleaver CLV-N2
Features Specifications FAQ Downloads



Features
  • Auto-Return Mechanism – Automatically returns the blade rail after each cleave for faster repetitive operation.
  • Integrated Fiber Dustbin – Collects fiber scraps during cleaving for cleaner and safer field operation.
  • 24-Position Blade – Provides extended blade utilization and consistent cleaving performance.
  • 48,000-Cleave Blade Life – Designed for long-term use and reduced blade replacement frequency.
  • FTTH Fiber Holder – Suitable for handling bare fiber and indoor cable during FTTH installation.
  • Multiple Fiber Compatibility – Supports 125 μm bare fiber and 250 μm / 900 μm coated fiber.
  • 5–20 mm Cutting Length – Accommodates different fiber preparation requirements.
  • Compact Design – Measures 60 × 60 × 100 mm and weighs 370 g, making it suitable for field use.
Specifications
Model CLV-N2
Product Type Fiber Cleaver
Bare Fiber Diameter 125 μm
Coating Fiber Diameter 250 μm, 900 μm
Cutting Length 5–20 mm
Blade 24 Positions
Blade Life 48,000 cleaves
Auto Return Yes
Fiber Dustbin Yes
FTTH Fiber Holder Yes – for bare fiber and indoor cable
Dimensions 60 × 60 × 100 mm
Weight 370 g
FAQ

Have a question to which you're seeking an answer ?

Type your question in the Search box , fill in your name, and email ID and press send.

We will respond with the answer. Rest assured that we respect your privacy, and your details will remain confidential.

Downloads

Product Datasheet

File Type: PDF File Size: 1.38 MB
View Download
