Laser Distance Meter Leica X310

The new Leica DISTO X310 is the only laser distance meter to be dust-tight and has protection against water jets (IP65). Additionally, it passes drop tests of up to 2 m height. The new unit offers even more features inside an updated ruggedized body able to withstand even the toughest conditions. Provides distance measurement indoors up to 80m and partially outdoors with an accuracy of +/- 1mm.

Specifications

Product Specification

Typical measuring accuracy ± 1 mm
Range 80 m
Measuring units 0.000 m, 0.0000 m, 0.00 m, 0.00 ft, 0‘00‘‘ 1/32, 0.0 in, 0 in 1/32
Power Range Technology
Distance in m Ø of the laser dot in mm 10, 50, 100 m 6, 30, 60 mm
Protection class IP65 – water jet protection and dust-tight
Measurements per set of batteries up to 5000
Batteries Type AAA 2 × 1,5 V
Dimensions 122 × 55 × 31 mm
Weight with batteries 155 g
Functions
Min/max measurement
Continuous measurement
Stake out function
Addition/subtraction
Area/volume
Painter function
Pythagoras 3 points, partial height
Smart Horizontal Mode •
Height tracking
Memory 20 Displays
Illuminated displayM
Multifunctional end-piece with automatic
recognition

Features

Features

  • IP65 water jet protection and dust-tight

  • 360° tilt sensor

  • Smart Horizontal ModeTM

  • Height tracking

  • Power Range TechnologyTM

  • Illuminated 4-line display

  • Automatic multifunctional end-piece

  • Holster

  • Hand loop

  • Batteries




Product Info Downloads

Product Info Downloads

Product Information files contain the essential technical detail you need to make informed decisions on any particular product. Simply click on a title to download a PDF copy of that file. If you wish a hard copy of a brochure, technical advice on any product or a demonstration then please contact us. We're always happy to help!

Title
File Type
File Size
Last Uploaded
application/pdf
1.01 MB
August 22 2014 00:50:24
application/pdf
4.2 MB
August 22 2014 01:08:54
